BS-T360 infront tracked skid loader is an excellent addition to farms, commercial spaces, specifically designed to handle loading, clearing and moving.
quality assurance (one year)
on-time delivery (shipping, air freight)
customized services (logo, packaging, graphic)
| model | BS-T360V |
| rated operating capacity / kg | 200 |
| maximum operating capacity / kg | 300 |
| maximum breakout force / kn | 3.5 |
| bucket capacity / m3 | 0.12 |
| driving speed / km/h | 0-6 |
| total cycling time / s | 9 |
| system operating pressure / bar | 17-21 |
| fuel tank capcity / L | 5 |
| operating weight / kg | 900 |
| tyre size | 15*72 |
| height at maximum extension / mm | 2450 |
| height to the bucket pin / mm | 1870 |
| vehicle height | 1300 |
| maximum height as lay the bucket flat / mm | 1810 |
| total length without appendages / mm | 1450 |
| length with standard bucket / mm | 2100 |
| maximum height unloading angle | 34¡ã |
| dumping height / mm | 1510 |
| discharge distance / mm | 450 |
| the flip angle of the bucket on the ground | 27¡ã |
| bucket flip angle at highest pos. | 114¡ã |
| wheel base / mm | 850 |
| ground clearance / mm | 150 |
| tail length / mm | 280 |
| wheel base (standard tire) / mm | 720 |
| vehicle width (standard tire) / mm | 880 |
| bucket width / mm | 1000 |
| engine brand | Bison BS192F / Briggs & Stratton |
| rated power kw / hp | 7.6kw / 10.07hp |
| rated speed / rpm | 3000 |
| number of cylinders | 1 |
| air intake way | naturally aspirated |
| displacement / cc | 420 |
| emissions standards | EUR 5-EPA |
